Product Description
Convert existing analog X-ray system to a low dose,high resolution Digital Radiography SystemDR retrofit kit includes a Flat Panel Detector, Medical Grid Monitor and an intuitive software for Image Acquisition & Image Processing.
overview
Flat Panel Detector
Wi-Fi
- Wireless Acquisition& Transfer
Scintillator
Digital Retina Technology
- Lightning Fast Acquisition
- Powerful Image Processing
- High Resolution Display
Full Field AED
Sensor
| Scintillator | Direct Deposit CsI : TI |
| Active Area | 433.7 x 354.8mm |
| Pixel Array | 2816 x 2304 |
| Pixel Pitch | 154μm |
Communication Interface
| Communication Interface | Gigabit Ethernet 2.4/5 GHz, 300Mbps |
| Image Acquisition Time | 2-3s (wired) and 4-5s (wireless) |
| Exposure Control | F²AED Manual Sync |
Environmental
| Operating Temperature Range | 5-35°C |
| Humidity Range (Non-condensing) | 30%-75% RH |
| Storage Temperature Range | -20-55°C |
| Humidity Range | 10%-90% RH |
Mechanical
| Dimensions | 460 X 384 X 15mm (18.11â X 15.11â X 0.59â) |
| Weight | 3.7 Kg (8.16 lbs.) |
| Housing Material | Carbon Fiber Front High Strength Aluminum Alloy Back |
Power
| Power Dissipation | 8W (Standby) 20W (Operating) |
| Power Supply | Power Supply |
| Frequency | 50/60Hz |
